Fig. 5.1
Fig. 5.2
The oven can be fitted in standard units,
width and depth 60 cm.
Installation requires a compartment as
illustrated in figures 5.1 and 5.2.
On the lower side, the oven must lay on
supports standing the oven weight.
Using 4 screws (not supplied) the oven
can be secured to the oven housing.
•
The appliance must be housed in heat
resistant units.
•
The walls of the units must be capa-
ble of resisting temperatures of 75 °C
above room temperature.
WARNING
When correctly installed, your product
meets all safety requirements laid down
for this type of product category.
However special care should be taken
around the rear or the underneath of the
appliance as these areas are not
designed or intended to be touched and
may contain sharp or rough edges, that
may cause injury.
INSTALLATION
5
