Other Features 5-49
DOB 1300-1556 PA-1639 Operator's Manual 2020 X3-45 Commuter
To Manually Raise The Platform
1. Verify that rollstop is up (closed). Pull rollstop
control knob out and rotate fully clockwise, if it isn’t
up.
2. Close the backup pump release valve by pushing
the actuating rod (A) DOWN (release valve should
already be closed).
NOTE
Pumping the handle raises the platform when the
release valve is closed.
3. Insert pump handle into backup pump socket (B),
then pump handle to raise the platform to the floor
level.
4. Position wheelchair in center of platform, facing
outward, and advise occupant to lock wheelchair
brakes. Power must be turned off on electric-
powered wheelchairs.
NOTE
Standee must stand near the center of the platform,
facing in the direction of travel (into vehicle), and
firmly grasp handrails. Do not stand on bridgeplate.
To Manually Lower The Platform
1. Verify that rollstop is up (closed). Pull rollstop
control knob out and rotate fully clockwise, if it
isn’t up.
2. Slowly pull the manual backup pump release
valve actuating rod (A) UP until the platform
begins to lower (opening the release valve lowers
platform).
3. Allow the platform to reach ground level.
To Next Page
