Controls and Instruments 4-37
DOB 1300-1556 PA-1639 Operator's Manual 2020 X3-45 Commuter
Pop-up Pictograms
Fire in engine compartment
This pictogram appears if a fire is detected in the engine compartment while the vehicle is
on the road. An audible alarm and the vehicle electric horn are activated to informs the
driver that a fire is detected. The vehicle fire suppression system (AFSS) display panel
will also show an alarm screen when a fire is detected. Refer to Section 7 "AUTOMATIC
FIRE SUPPRESSION SYSTEM (AFSS)" on page5 for more information.
WARNING
In case of a fire, stop the vehicle immediately, stop the engine and evacuate the vehicle.
NOTE
It is possible to cancel the horn alarm while on the road. To do so, stop the vehicle.
Cycle the ignition twice between the ON and OFF position and then start the vehicle
normally.
NOTE
To stop the electric horn alarm when parked, cycle the ignition between the on and off
position twice within 2 seconds.
For the location of the extinguisher, refer to Section 7 Safety Features And Equipment
"FIRE EXTINGUISHER" on page4.
