CAVA - MANUAL
1 | CAVA – Manual | AntecControls.com
Technical Specifications
Environmental
(Operating)
32°F to 130°F (0°C to 55°C), 5% to 95% R.H. (Non-Condensing)
Environmental
(Storage)
-22°F to 158°F (-30°C to 70°C), 0% to 95% R.H. (Non-Condensing)
Input Power
24 VAC ±10%, 50/60 Hz, 12 VA Max (excluding external loads), Class 2
Inputs
4 Universal Inputs (Includes sidewall
and sash-position sensor inputs)
Binary Input (Contact Closure or Active)
Analog Input (0 – 10 VDC)
Resistance Input – Sash Position (0 – 50 kΩ)
Control Area Network (CANbus)
3 Room Information Network (RIN) Ethernet Ports
RS-485 Network (BACnet)
Outputs
2 Binary Outputs (Max: 24 VAC, 500 mA)
Indicators
4.3” LCD Capacitive Touch Screen
Audible Alarm
Buttons
Mute Alarm
Emergency Mode
Housing
UL 94V-0, PC-ABS Plastic
Communication
Protocol
BACnet
BACnet
Device Type
B-AAC
Communication Type
MS/TP (RS-485)
Communication Speed
9600, 19200, 38400, 76800 Baud Rate
Certification
BTL
Control Priority Order
1. BACnet
2. Normal operation
