12 www.pridemobility.com Lift Chair Series
LIFT CHAIR SERIES
IV. ASSEMBLY/DISASSEMBLY
Your lift chair may require some assembly before initial use. It may also require disassembly to
make servicing the chair more convenient. If your lift chair is a Knock-Down (KD) model, follow
the instructions in “Lift Chair Setup.” If your lift chair is not a KD model, proceed to “Lift Chair
Placement.”
LIFT CHAIR SETUP
KD models will arrive in the knock-down position (Fig. 4.1).
Figure 4.1 Knock-Down (KD) Position
Follow these steps to assemble the lift chair:
NOTE: Depending on chair width, you may need to slide on one side of the chair-back at a time.
If this is the case, level the chair-back before pressing down to lock into position.
4.1.2 Drape the hand control and cable over the
chair base, then slide the left and right KD
sleeves of the chair-back onto the KD con-
nections on the arms and seat of the chair.
4.1.1 Remove the packaging from the back portion
of the chair and check that the locking clip is in
the vertical position. Reposition if necessary.
