Pride Mobility Go-Go Series User Manual

26 Go-Go
VIII. DISASSEMBLY AND ASSEMBLY
Figure 15A. Toggle Latch (Unlatched)
Toggle Latch Release
1. Push in the toggle latch release button while pulling forward on the toggle latch. See figure 15.
2. Rotate the toggle latch buckle over the top of the toggle latch until it snaps into its retainer. See figure 15A.
.
3. Remove the battery pack.
n The battery pack is held in place by a reusable fastener. Use the battery pack handle to pull the battery pack
up and away from the scooter. See figure 13.
4. Unplug the front-to-rear harness. See figure 14.
Figure 13. Removing Battery Pack Figure 14. Front-To-Rear Harness
TOGGLE
LATCH
TOGGLE
LATCH
RELEASE
BUTTON
Figure 15. Toggle Latch (Latched)
TOGGLE
LATCH
BUCKLE

Pride Mobility Go-Go Series Specifications

General

Weight Capacity	300 lbs
Overall Width	21 inches
Front Tires	8 inches solid
Rear Tires	8 inches solid
Battery Size	12V 18Ah (x2)
Charger Type	Off-board
Seat-to-Ground Height	19.5 inches
