Pride Mobility GOPHER - 3 Parts Introduction; Parts Description

9
3. PARTS INTRODUCTION
3.1 PARTS DESCRIPTION
1. Indicator Lamp 2. Charger Socket Cover 3. Basket Bracket
4. Tiller Adjust Lever 5. Head Lamp 6. Seat Remove Lever
7. Seat Slide Lever 8. Armrest 9. Freewheel Lever
10. Side Reflector 11. Rear Lamp 12. Anti-tip Wheel
13. Rear Reflector 14. Width Adjustable Armrests Knob
15.Rear Indicator Lamp 16. Rear View Mirror
.
1
2
3
4
5
6
10
7
9
8
14
12
15
11
1
3
16
j\\
6
