Pride Mobility GOPHER - 7 Trouble Shooting and Specification

19
● TROUBLE SHOOTING
Symptom
Remedy
The scooter will not switch on
Try recharging the battery
Check the fuse and circuit breaker in the scooter
The scooter switches on, but the
scooter will not move.
Ensure there is enough power in the batteries. If not,
recharge the batteries.
Ensure the freewheel lever is engaged in the „DRIVE‟
position.
The scooter appears slow
Check the battery power level and recharge
Check the speed dial is not set to slow.
The seat turns when in operation
Slowly rotate the seat until it drops in to place and is
secure
The handlebar appears loose
Tighten the height adjustment handle to secure the
handlebar
Involuntarily horn sounds
Ensure that the wigwag paddle is released.
Switch the scooter off and on.
Recharge the batteries.
If problem persists contact your WU‟S dealer.
● SPECIFICATION
Remark: The manufacturer reserves the right to modify the specification if necessary. The final
specification is subject to the individual scooter you purchase from your dealer.
Note:
Maximum driving distance is based on an ambient temperature of 20 C, a 75kg driver and a
brand new fully charged battery by a constant driving speed at 6.4 km/h with 70% battery power
discharged.
7. TROUBLE SHOOTING AND SPECIFICATION
Model Reference
Gopher
Gopher DX
Dimension
(L x W x H mm)
1200 x 580 x 1030 mm
1200 x 580 x 1220 mm
Weight w/i (36Ah) battery
without battery
87 kg
93 kg
63 kg
69 kg
Battery
36 AH (option 50AH)
Charger
CTE 4A
Front Tyre
300-4, 10” Solid Tyre
Rear Tyre
300-4, 10” Solid Tyre
Driving System
Direct drive the rear wheels ( with differential gear)
Brake System
Electromagnetic brakes
Control Method
By speed control lever
Max Speed
6 KMH
10 KMH
Climbing angle
<8°
Cruising range
20-30km (with 36Ah battery)
30-40km (with 50Ah battery)
Weight Capacity
160 kg
