VIII. BASIC TROUBLESHOOTING
What if all the systems on my scooter seem to be “dead”?
Make certain that the key is in the “on” position.
Check that the batteries are fully charged.
Push in the main circuit breaker reset button. See III. “Your Scooter .”
Make certain that both T-handle battery harnesses are firmly connected to the rear section and to the
battery terminals. See VII. “Disassembly and Assembly.”
Make sure that the front-to-rear harness is firmly connected to the rear section. See VII. “Disassembly
and Assembly.”
Be sure the power down timer feature hasn’t been activated. See V. “Operation.”
Check the 3-amp fuse located on the lower portion of the tiller console. See IX. “Care and Mainte-
nance” for fuse replacement.
DIAGNOSTIC FLASH CODES
The diagnostic flash codes for your scooter are designed to help you perform basic troubleshooting quickly
and easily. A diagnostic flash code will flash from the status LED in the event one of the conditions listed
below develops.
NOTE: Your scooter will not run unless the flash code condition is resolved and the scooter has been
turned off, then turned back on.
Any electromechanical device occasionally requires some troubleshooting. However, most of the
problems that may arise can usually be solved with a bit of thought and common sense. Many of these
problems occur because the batteries are not fully charged or because the batteries are worn down and can
no longer hold a charge.
Flash Code Condition Solution
(1)
Battery voltage is too low to operate the
scooter or the charger is operating.
Charge batteries or unplug the charger power cord
from the electrical outlet.
(2)
Motor disconnected. Check all connections to the motor.
(3)
Motor wiring fault. Call your authorized Pride Provider for assistance.
(6)
Scooter is operating with the charger
attached.
Unplug the charger power cord from the off-board
charger port.
(7)
Throttle trip. Throttle potentiometer fault
or speed potentiometer fault.
Call your authorized Pride Provider for assistance.
(8)
Internal controller fault. Call your authorized Pride Provider for assistance.
(9)
Brake fault - your scooter was left in free-
wheel mode.
Turn the scooter key to the “off” position, then push
the manual freewheel lever to the drive position, and
restart your scooter.
(10)
High battery voltage. The batteries have
been overcharged and the scooter won’t
run.
Leave the scooter turned on to drain the batteries to
a sufficient level. If the batteries continue to over-
charge, call your authorized Pride Provider for assis-
tance.
