Pride Mobility OUTBACK - Dimensional Diagram

40
www.pridemobility.com Outback
APPENDIX I - SPECIFICATIONS
Figure 19. Outback Dimensions
196 cm (77”)
41 cm (16”)
46 cm (18”)
64 cm (25”)
79 cm (31”)
160 cm (63”)
Turning Radius
18 cm (7”)
5 cm (2”)
63-71 cm (25-28”)
20 cm (8”)
133 cm (52.5”)
80°
48-58 cm (19-23”)
