Outback www.pridemobility.com
APPENDIX I - SPECIFICATIONS
Model Number PMV600
Overall Length
2
See figure 19.
Overall Width
2
See figure 19.
Tyres Type: Pneumatic Front: 15 x 33 cm, Rear: 15 x 33 cm (6 x 13 in.)
Wheels Aluminum alloy wheels in Black
Weight Capacity 181.4 kg, (400 lbs.) maximum
Battery Type
3
(not included) Two 12V, 100 Ah
Horsepower 3.0 hp (peak)
Charger Onboard 8-amp charger
Speed (Max)
1
Variable up to 16 km/h (60% reverse)
Maximum Grade See figure 1.
Range
1
Up to 30-35 miles per charge with 100 Ah batteries
Turning Radius
2
See figure 19.
Seating Style: High-back with headrest and sliders
Dimensions: See figure 19.
Seat Cover Material: Vinyl; Black, Grey, Tan, or Brown
Armrests: Match seat cover material
User adjustable seat height from ground: 70.49-80.65 cm (27.75 - 31.75 in.)
User adjustable seat height from deck: See figure 19.
Brakes Electronic regenerative braking and electromechanical disc brake
Rear Wheel Drive 2-24 VDC motors
Weight Total weight with batteries: w/two 12V, 100 Ah batteries: 156.4 kg (345 lbs.)
Total weight without batteries: seat and rear shroud: 97.98 kg (216 lbs.)
Component Breakdown:
Rear Plastic Shroud:1.59 kg (3.5 lbs.)
Seat: 16.78 kg (37 lbs.)
Batteries: 28.58 kg each (63 lbs.)
Ground Clearance
2
See figure 19.
1
Varies with user weight, terrain type, battery amp-hour (Ah), battery charge, battery condition, and tyre condition. This
specification can be subject to a variance of (+ or -) 10%.
2
Due to manufacturing tolerances and continual product improvement, this specification can be subject to a variance of (+
or - ) 3 %.
3
AGM or Gel-Cell type required. See IV. “Batteries and Charging.”
NOTE: This product conforms to all applicable ANSI-RESNA testing requirements and ISO 7176 Series
EN12184 standards. All specifications subject to change without notice.
