29
Sonic www.pridemobility.com
ARMREST WIDTH ADJUSTMENT
The armrest width can be adjusted inward or outward.
See figure 17A.
1. Remove the detent pins located near the armrest ad-
justment knobs.
2. Loosen the armrest adjustment knobs.
3. Slide the armrests in or out to the desired width.
4. Reinsert the detent pins through the adjustment holes
of both the seat frame and armrest frame.
5. Tighten the armrest adjustment knobs as required.
NOTE: Pivot the armrests upward to aid in getting
onto and off of your scooter.
VII. COMFORT ADJUSTMENTS
Figure 17A. Armrest Width Adjustment
DETENT PIN
ARMREST ADJUSTMENT KNOB
