www.pridemobility.com Elite Traveller Plus/Plus HD
Model Numbers Elite Traveller Plus: SC53, SC54
Elite Traveller Plus HD: SC53HD, SC54HD
Colors Red, Blue, Silver (interchangeable panels)
Overall Length
2
3-wheel: 40 in. (101.6 cm)
4-wheel: 40.25 in. (102.24 cm)
Overall Width
2
21.12 in. (53.64 cm)
Total Weight Without Batteries 3-wheel: 86.5 lbs. (39.24 kg)
4-wheel: 87 lbs. (39.46 kg)
Heaviest Piece When Disassembled 3-wheel: Rear Section (32.5 lbs./14.74 kg)
4-wheel: Front Section (35 lbs./15.88 kg)
Turning Radius
2
3-wheel: 34 in. (86.36 cm)
4-wheel: 45.75 in. (116.2 cm)
Speed (maximum)
1
Variable up to 4.5 mph (7.24 km/h)
Range Per Charge
1
Up to 13 miles (21 km) with 17 Ah batteries
Ground Clearance
2
3 in. (7.62 cm) at mid-frame
Weight Capacity Elite Traveller Plus: 300 lbs. (136 kg)
Elite Traveller Plus HD: 325 lbs. (147.42 kg)
Standard Seating Type: Foldable moulded plastic
Material: Black Vinyl
Drive System Rear-wheel drive, sealed transaxle, 24 volt DC motor
Dual Braking System Electronic, regenerative and electromechanical
Tires Type: solid (flat-free inserts)
Front: 2 in. x 8 in. (5 cm x 20.32 cm)
Rear: 3 in. x 9 in. (7.63 cm x 22.86 cm)
Battery Requirements
3
Type: Two 12-volt, deep-cycle
Size: 17 Ah
Battery Pack Weight 29 lbs. (13.15 kg)
Battery Charger Off-board charger
APPENDIX I - SPECIFICATIONS
1
Varies with user weight, terrain type, battery amp-hour (Ah), battery charge, battery condition, and tire condition.
This specification can be subject to a variance of (+ or -) 10%.
2
Due to manufacturing tolerances and continual product improvement, this specification can be subject to a
variance of (+ or – ) 3 %.
3
AGM or Gel-Cell type required. See IV. “Batteries and Charging.”
NOTE: All specifications subject to change without notice.
