Transaxle/Motor/Brake Assy
(Includes B1, C1, & D1)
Motor/Brake Assy
(Includes C1)
Brake
Transaxle Assy
When applicable, assemblies are grouped
by color. All components with that color
are included in the assembly.
A1
B1
C1
D1
II. Drive Assembly
A1
B1
C1
D1
REF #
DRVASMB2322
DRVASMB2323
DRV1099
DRVASMB2023
PART #
MOTOR,ASSY,MAIN TRANSAXLE/MOTOR/BRAKE,T1 W/LIHOO 6
CONNECTOR,E-1211-030,(FSN: FS180-00-19)
MOTOR,ASSY,MOTOR/BRAKE,FSN,(FSN: FST1-180-01-19)
BRAKE,3NM,24VDC,CLOCKWISE,4.5" WIRE LENGTH W/MOLEX
CONNECTOR,H-1215-001,(WARNER: WR225A48P1)
TRANSAXLE,ASSY,FSN STD LINK SHAFT,W/HARDWARE,TRAVEL
PAL,(FS180)
DESCRIPTION
1
1
1
1
QTY
$269
$264.6
$36.84
$102.14
Dealer $
$685.95
$674.73
$93.95
$260.45
MSRP
