Pride Go-Go ES8 User Manual

Go-Go ES8
8 Rev.F/020617
®
G1
H1
3-Wheel
4-Wheel
Top Console Assy
(Includes B1 & C1)
Speed Pot Knob
Speed Pot Harness
Bottom Console Shroud
Throttle Pot
Throttle Control Lever
3-Whl Front to Rear Harness
4-Whl Front to Rear Harness
A1
B1
C1
D1
E1
F1
G1
H1
Front to Rear
Harness
When applicable, assemblies are grouped
by color. All components with that color
are included in the assembly.
III. Electronics Assembly — Console
A1
B1
C1
D1
E1
F1
G1
H1
REF #
ELEASMB7136
DWR9983B030
DWR1020H161
SHDASMB6193
ELEASMB7342
FRMASMB17085
DWR9983H028
DWR9983H043
PART #
ELECTRONIC,ASSY,TOP CONSOLE,GO-GO ES,H-9983-036
KNOB,GRAY,PLASTIC,SPEED POT,B-9983-030
ELECTRONIC,SPEED POT W/HARNESS,CTS,100K,H-1020-161
SHROUD,ASSY,CONSOLE BOTTOM,BLACK,GO-GO ES
ELECTRONIC,ASSY,THROTTLE POT,GO-GO ES
LEVER,ASSY,THROTTLE CONTROL,GO-GO ES
ELECTRONIC,HARNESS,FRONT-TO-REAR,TRAVEL PRO 8
ELECTRONIC,HARNESS,FRONT-TO-REAR,ES-8,4 WHEEL,H-9983-043
DESCRIPTION
1
1
1
1
1
1
1
1
QTY

Pride Go-Go ES8 Specifications

General

Brand	Pride
Model	Go-Go ES8
Category	Scooter
Language	English
