Introduction
2
TECHNICAL SPECIFICATION
Output power per channel 2 x 70W into 8Ω, 2 x 110W into 4Ω
Speaker terminals 4 –16Ω
Output impedance <0.08Ω
DC offset <5mV
Line inputs 330mV
Tape outputs 300mV
Frequency response <10Hz – 100kHz, -3dB
THD 0.08% (1kHz, 10V into 8Ω)
Signal-to-noise, line -98dB (A-weighted)
Power consumption, standby <16W
Peak current ±20A
Dimensions (WxDxH) 430 x 275 x 95mm
Weight 11kg
