7
Connecting the A30.1 Integrated Amplifier
This chapter explains how to connect the A30.1 to the other components in your
system, using the connections on the back panel.
]E Left preamplifier output.
]F Ground terminal.
]G Tape1 outputs.
]A Right loudspeaker outputs.
]B Balanced XLR Inputs.
]C Line RCA inputs.
]D Left loudspeaker outputs.
BACK PANEL CONNECTIONS
]H Tape outputs.
]I Right preamplifier output.
]J Mains power input and fuse.
RIGHT SPEAKER PRE-OUT
RIGHT
– +
LEFT SPEAKER
+ –
L
R
BALANCED INPUT 1
LR
BALANCED INPUT 2
TAPE1
OUT
TAPE
OUT
CD TUNER AUX TAPE1
GROUND
PRE-OUT
LEFT
]G]F ]H ]I ]J]E
]D]C]A ]B
