Introduction
2
Burn-in
Due to the circuit used in the A32, it requires a significant burn-in period
before it will perform at its maximum.
USING THE A32 WITH OTHER PRIMARE PRODUCTS
Although the A32 is flexible enough to act as the output stage in virtually any
system, it is ideal for use with other products in the Primare range, such as the
Primare PRE30 Preamplifier and CD31 Compact Disc Player, and one or more
A32 amplifiers can be powered on or off remotely from a PRE30 using the
remote trigger output.
TECHNICAL SPECIFICATION
Output power per channel 250W into 8Ω, 400W into 4Ω
Unbalanced inputs 2 x RCA connectors
Balanced inputs 2 x XLR connectors
Input impedance 15kΩ
Gain 26dB unbalanced, 20dB balanced
Frequency response 20Hz to 100kHz, -0.5dB
THD+N <0.05% 20Hz to 20kHz at rated power
Noise <-100dBV
Trigger input 4 to 15V
Dimensions (WxDxH) 43 x 54 x 23mm
Weight 40kg
