Primary Mover
Mandeville, Louisiana
Page 16
Maximum Hydraulic Flow Rate 2 GPM Port
Maximum Pressure For “Raising” Portion of Cycle 3200 PSI A
Single Acting HPU Connections
Hoist
Cylinder
IMPORTANT:
Install (supplied) Bridon
load control valve at this
port of hydraulic cylinder
Install vented plug (supplied) in this
port. To qualify for extended warranty
a hose must be installed here.
Contact Primary Mover for instructions.
