PrimeLog User Manual
14
2 Appendices
2.1 Appendix 1: Meter Scaling Tables
2.1.1 Kent Domestic, Helix & Master Meters
Pulse Unit Types
Meter PU10/LRP PU100/HRP
PD100
BPG20 PG100
(4000 Reed)
PSM MSM
TYPE SIZE (mm) FCAL
Helix 2000 40-80 10 1
100-300 100 10
Helix 3000 40-80 10 1
*100 10 1
150 100 10
Master 2000 40-50 1 0.1
80-100 10 1
Helix WP4000 80-125 1 10/100
150-300 10 100/1000
PSM-PS15-
PS20
15-20 0.5 ** 5
PSM-PS25-
PS30
25-30 5 ** 50
PSM-PS40 40 5 ** 5
PSM-LT 15 0.5
MSM-T ALL 1
MSM-RS ALL 10
2.1.2 Schlumberger Domestic & Helix Meters
Pulse Unit Type
CYBLE CYBLE LF
METER
S* TLOS HF K=2.5 K=5 K=10 K=25 K=100 K=1000
Type Size (mm) FCAL
Aquadis 15-20 1 0.01 0.1 0.25 0.5 1 2.5 10 100
25-30 10 0.05 1 2.5 5 10 25 100 1000
40 10 0.1 1 2.5 5 10 25 100 1000
P40M All 1 0.01 1 2.5 5 10 25 100 1000
Flowstar M 40 100 1 1 2.5 5 10 25 100 1000
50-100 100 1 10 25 50 100 250 1000 10000
Woltex 50-100 100 1 10 25 50 100 250 1000 10000
150-300 1000 10 100 250 500 1000 2500 10000 100000
400-500 10000 100 1000 2500 5000 10000 25000 100000 1000000
Woltmag V 50-100 100 2 10 25 50 100 250 1000 10000
