2.1.3 Socam Domestic & Helix Meters
Pulse Unit Types
METER
K510
*
K505R R02.2 RD
022
OD 06 OPTO
06
Type Size (mm) FCAL
0.5
510PR Qn 1.5 - 2.5 1
Qn 1 - 1.5 -
2.5
10 0.5
501LM Qn 1 - 1.5 -
2.5
100
1000
510PR
501JM
Qn 3.5 - 6 - 10
Qn 1.5 - 10
5
10
100
1000
5
Cosmos II 50-125
150-300
400-500
100
1000
10000
1
10
100
Cosmos
WPD /
Galaxy
50-125
150-250
300-800
100
1000
10000
1
10
100
2.1.4 Supplementary Notes for Meter Scaling Tables
FCAL = NO. LITRES PER PULSE
2.1.4.1 Kent Meters:
* Some earlier 100mm meters require the following:
FCAL = 100(PU10/LRP) or 10(PU100/HRP). These meters can be distinguished by the
centre pointer dial registration = 1000 litres/rev.
** Applies to 7 digit counters only, the other FCAL’s apply to the 8 digit counters.
Kent combination meters use a Helix 3000 meter as the main meter and a PSM-T as the
secondary meter. Select the appropriate FCAL from the table above for each of the meters.
Master 2000 has been discontinued.
2.1.4.2 Schlumberger meters:
* It should be noted that the ‘S’ pulse unit is factory fitted and that various outputs can be
specified at this time. The individual meter should be checked before selecting the
appropriate FCAL.
Schlumberger combination meters use a Woltex meter as the main meter and a Flowstar as
the secondary meter. Depending on the size mix, select the appropriate FCAL from the table
above for each of the meters.
