LAYOUTOPERATION
Safety Trigger Operation
The AG60 torch supplied with the CT520D machine has a new design of safety trigger.Just pull
back on the trigger whilst increasing your grip and you will feel the trigger move to the on position.
When you release the pressure it will return to the o󰀨 position.
OFF ON OFF
Power cable connection
Power cable
Brown
Hot Wire
Blue
Neutral Wire
Yellow
Ground Wire
