PrimeWeld CT520D - Parameter Specifications; INPUT;OUTPUT SPECIFICATIONS

7
PARAMETER
INPUT/OUTPUT SPECIFICATIONS
IGBT Inverter Type: IGBT
Voltage/phase: Dual Voltage 120/240 1 Phase
TIG output type: DC only
TIG Start Type:
High Frequency Only
Pulse: No
Plasma Cutter Arc Start Type: High Frequency
PilotArc: No
OK-to-Cut Indicator/Low Air pressure safety: No
OCV:
▪ TIG: 70 V
▪ Stick: 70 V
▪ Plasma: 220V
Max Inrush ( I1MAX ) Amps:
▪ @ 110V: 31A
▪ @ 220V: 27A
Maximum Rated (I1EFF ) Input Amps:
▪ @110V: 19A
▪ @220V: 17A
TIG Output Amps/Volts @ Rated Duty Cycle:
120V:
▪ 120A/14.8V @ 35% Duty Cycle
▪ 93A/13.7V @ 60% Duty Cycle
▪ 72A/12/9V @ 100% Duty Cycle
240V:
▪ 200A/18V @ 35% Duty Cycle
▪ 160A/16.4V @ 60% Duty Cycle
▪ 130A/15.2V @ 100% Duty Cycle
Stick Output Amps/Volts @ Rated Duty Cycle:
F120V:
▪ 120A/24.8V @ 35% Duty Cycle
▪ 93A/23.7V @ 60% Duty Cycle
▪ 72A/22.9V @ 100% Duty Cycle
240V:
▪ 160A/26.4V @ 35% Duty Cycle
▪ 130A/25.2V @ 60% Duty Cycle
▪ 100A/24V @ 100% Duty Cycle
Plasma Output Amps/Volts @ Rated Duty Cycle:
120V:
▪ 27A/90.8V @ 60% Duty Cycle
▪ 21A/88.4V @ 100% Duty Cycle
240V:
▪ 50A/100V @ 35% Duty Cycle
▪ 40A/96V @ 60% Duty Cycle
▪ 30A/92V @ 100% Duty Cycle
TIG DC Amp/Volt Range:
▪ 120V: 10A-120A, 10.4V-14.8V
▪ 240V: 10A-200A, 10.4V-18V
Stick Amp/Volt Range:
▪ 120V: 10A-120A, 20.4V-24.8V
▪ 240V: 10A-160A, 20.4V-26.4V
Plasma Amp/Volt Range:
▪ 120V: 10A-27A, 84V-94V
▪ 240V: 10A-50A, 84V-100V
Preow time: Fixed
Post Flow Time: Fixed
OverCurrent Protection: Yes
