Primus ECM Series - Specification

ECM-SERIES 2
User’ Guide
The Electronic Enclosure Cooling ModuleType ECM-Series has been designed and made to maintain the
internal temperature inside the control cabinet by producing the cool air inside the control cabinet to prevent any
damages to the equipment that is sensitive to the changing of temperature.
The Cooling Module is suitable to be used where the ambient temperature are about +40 ํC to +50 ํC,
whereas the ordinary air conditioner cannot be used where the ambient temperature is too high.
Application
1.
Specification
2.
MODEL UNITS
ECM-1000
ECM-1000
SUS
ECM-2700
ECM-2700
SUS
ECMV-4000 ECMV-4000
SUS
ECM-7000 ECM-7000
SUS
Material
-
Steel
SUS304
Steel
SUS304
Steel
SUS304
Steel
SUS304
Steel
SUS304
Steel
SUS304
Supply Voltage V-Ph-Hz 220-240/1/(50/60Hz) 220-240/1/(50/60Hz) 220-240/1/50Hz
Cooling Capacity L35L35 W 330 800 1400 2000 1400
Cooling Capacity L35L50 W 270 680 1170 1700 1170
Cooling Capacity BTU/h 1000 2700 4000 7000 4000
Dimension
(Width/Height/Depth)
mm 330/430/181 310/635/210 412/930/255 412/930/252.5 604/360/450
Max Running Current A 1.2 2.1 4 4.7 4
Start Current A 5 12 17 20 17
Start Delay Time (D1) min. 1 - 60 (Default 3 minute)
Sensor Delay Time (D2) min. 1 - 60 (Default 1 minute)
Recovery Time (D3) min. 1 - 60 (Default 1 minute)
Condensor Fan Air Flow m
3
/h 188 460 593 1220 367
Evaporation Fan Air Flow m
3
/h 115 300 312 780 675
Condensor Fan Power
Consumption/Current
W/A 35/0.29 62/0.28 62/0.28 87/0.44 87/0.44
Evaporation Fan Power
Consumption/Current
W/A 18/0.12 35/0.29 62/0.28 62/0.28 62/0.28
Internal Temperature Limits
o
C 25-45
Outter Temperature Limits
o
C 20-55
Internal Protection Degree IP IP54
External Protection Degree IP IP30 IP34
Protection
System
Clot Water Pipe -
√ √ √ √
Compressor - -
√ √ √
Refrigerant Charge kg 0.25 0.35 0.65 0.65 0.6
Refrigerant R 134a 134a
Noise Level
(Max)dB 57.9 67.3 67.0 70.6 67.0
Weight kg 19 29 45 48 50
3800
2700
13000
505/1230/370
8.8
38
1231
1891
189/0.94
189/0.94
√
√
1
R404
75.0
92
ECM-4000
SUS
ECM-4000 ECM-13000
SUS
ECM
-
13000
220-240/1/50Hz
