5 ECM-SERIES
User’ Guide
Connecting the cooling module to the main electric supply, the voltage and frequency must be checked
to be the same value with the specification.
The cooling module must be connected to the main via isolating device, do not use any additional Thermostat
connected before.
Line protection should be provided by means of the breaker specified onthe specification on the user’s guide.
Do not connect the Neutral with the ground rod in the earth that is connected to the electric line. This
practice will cause the under voltage and damage the coolers.
Remark :
The air coolers are properly work, LED will display continuously green
• Tighten the Electrical line and Neutral connection • Voltage and current check while the unit is still running
Precaution
Importance
The cooling module consists of four main components; the coolant compressor, evaporator, condenser
and the pressure control which are connected by suitable pipe work (350Psi). Pressure tested before filled with
a readily boiling substance; the coolant. All the fault signal, protection and the temperature controller of the air
cooler are controlled by a Hiprosent Control electronic board.The next generation control will be a Microprocessor
control board, for more function and more output.
Fault signal and protection
5.1
To drain the condensate water from the air cooler drain pan, a hose should be connected to the
aluminium pipe of the of the cooling module and route the hose directly downward.
Condensate discharge
5.2
The Electronic Enclosure Cooling Module Type ECM-Series are very easy to maintenance. The fin coil
of cooling module should be constantly cleaned under supervisor two times a year.
Warranty :
One year warranty commencing from the purchased date.
Storage, the cooling module should not be stored / keep to temperature above 70 C. Transportation,
The cooling module must be transported upright.
Remark :
If the cooling module are not correctly positioned during transporting compressor might be
damage. Old and worn out of cooling module should be send back to themanufacturer in order to destroy
properly to prevent and harmful consequence to the remaining of refrigerant and lubricant inside the compressor
General Instruction
5.3
Electrical Connection
4.
Technical Information
5.
Maintenance and Warranty
6.
