Primus ECM Series - Technical Specification

ECM-SERIES 8
User’ Guide
ECM-1000
WALL TYPE
TECHNICAL SPECIFICATION
MODEL
UNITS
ECM-1000 ECM-1000SUS
Supply Voltage V-Ph-Hz
Cooling Capacity L35L35 W 330
Cooling Capacity L35L50 W 270
Cooling Capacity BTU/h 1000
Dimension
(Width/Height/Depth)
mm 330/430/181
Max Running Current A 1.2
Start Current A 5
Start Delay Time (D1) min.
Sensor Delay Time (D2)
min.
Recovery Time (D3) min.
Condensor Fan Air Flow m
3
/h 188
Evaporation Fan Air Flow m
3
/h 115
Condensor Fan Power
Consumption/Current
W/A 35/0.29
Evaporation Fan Power
Consumption/Current
W/A 18/0.12
Internal Temperature Limits
o
C
Outter Temperature Limits
o
C
Internal Protection Degree IP
External Protection Degree IP IP30
Protection
System
Clot Water
Pipe
-
Compressor
-
Refrigerant Charge kg 0.25
Refrigerant R
Noise Level (Max) dB 57.9
Weight kg 19
1-60 (Default 3 minute)
1-60 (Default 1 minute)
1-60 (Default 1 minute)
25-45
20-55
IP54
134a
220-240/1/(50/60Hz)
Material
-
Steel SUS304
