Primus ECM Series - Page 11

9 ECM-SERIES
User’ Guide
ECM-2700
WALL TYPE
TECHNICAL SPECIFICATION
MODEL
UNITS
ECM-2700 ECM-2700SUS
Supply Voltage V-Ph-Hz
Cooling Capacity L35L35 W 800
Cooling Capacity L35L50 W 680
Cooling Capacity BTU/h 2700
Dimension
(Width/Height/Depth)
mm 310/635/210
Max Running Current A 2.1
Start Current A 12
Start Delay Time (D1) min.
Sensor Delay Time (D2)
min.
Recovery Time (D3) min.
Condensor Fan Air Flow m
3
/h 460
Evaporation Fan Air Flow m
3
/h 300
Condensor Fan Power
Consumption/Current
W/A 62/0.28
Evaporation Fan Power
Consumption/Current
W/A 35/0.29
Internal Temperature Limits
o
C
Outter Temperature Limits
o
C
Internal Protection Degree IP
External Protection Degree IP IP34
Protection
System
Clot Water Pipe
√
Compressor -
Refrigerant Charge kg 0.35
Refrigerant R
Noise Level (Max) dB 67.3
Weight kg 29
1-60 (Default 3 minute)
1-60 (Default 1 minute)
1-60 (Default 1 minute)
25-45
20-55
IP54
134a
220-240/1/(50/60Hz)
Material
-
Steel SUS304
