Primus ECM Series - Page 12

ECM-SERIES 10
User’ Guide
ECMV-4000
WALL TYPE
TECHNICAL SPECIFICATION
MODEL
UNITS
ECMV-4000 ECMV-4000
SUS
Supply Voltage V-Ph-Hz
Cooling Capacity L35L35 W 1400
Cooling Capacity L35L50 W 1170
Cooling Capacity BTU/h 4000
Dimension
(Width/Height/Depth)
mm 412/930/255
Max Running Current A 4
Start Current A 17
Start Delay Time (D1) min.
Sensor Delay Time (D2) min.
Recovery Time (D3) min.
Condensor Fan Air Flow m
3
/h 593
Evaporation Fan Air Flow m
3
/h 312
Condensor Fan Power
Consumption/Current
W/A 62/0.28
Evaporation Fan Power
Consumption/Current
W/A 62/0.28
Internal Temperature Limits
o
C
Outter Temperature Limits
o
C
Internal Protection Degree IP
External Protection Degree IP IP34
Protection
System
Clot Water Pipe
√
Compressor
√
Refrigerant Charge kg 0.65
Refrigerant R
Noise Level (Max) dB 67.0
Weight kg 45
1-60 (Default 3 minute)
1-60 (Default 1 minute)
1-60 (Default 1 minute)
25-45
20-55
IP54
134a
220-240/1/50Hz
Material
-
Steel SUS304
