PRISM+ XQ340 PRO - Product Overview; Monitor Buttons; Monitor Ports

6
Section 3: Product Overview
3.1 – Monitor Buttons
8
Audio Output: Insert one end of the audio cable into an external audio
source, e.g., speakers or headphones, to pass audio signals through the
monitor.
9
DP Connector: Insert one end of the DP cable into the computer’s DP output
and connect the other end to the monitor’s DP port.
10
HDMI Connectors: Insert one end of the HDMI cable into the computer’s
HDMI output and connect the other end to the monitor’s HDMI port.
7
Power Connector: Insert the power cable to supply power to the monitor.
7
8
1
M Menu Button: Press to display the OSD menu or enter sub-menus.
2
Down Button: Press to navigate down in the menus.
3
Up Button: Press to navigate up in the menus.
4
E Exit Button: Press to exit.
5
Power Button: Press to turn on/off the monitor.
6
LED Indicator: Changes colors to indicate status. Refer to Section 8.
3.2 – Monitor Ports
9 10
