Section 5: Mount Installation
Take out the monitor from the box and gently place it on the foam on a stable,
flat table. Remove the shaft assembly.
Take out the four hexagonal spacer screws with a height of 35mm from the
accessory bag, and fasten them into the M4 threaded hole of the rear tank sinking
slot with a screwdriver (not included). It is advised to place the monitor on top of the
foam to prevent breaking the screen.
Install the monitor on the wall mount or bracket as desired.
VESA and mounting accessories are not included.
