8
Take out shaft assembly part and stand stem. Use 2 pcs of 11mm screws to
fasten them. As shown in the picture below, use 1pc of 11mm screw
to fasten the stand stem and stand base.
Based on the picture below, place the well assembled stand to the corresponding
slot at the back cover and ensure the shaft assembly is well attached to the monitor.
Gently lift the monitor up and ensure that the monitor is well attached.
To dismantle, operate by reversing the installation steps.
Gently lift your monitor to an upright position.
Note: Do removed the foam attached to the monitor panel when lifting the
monitor. Do not lift the monitor by holding on the screen to prevent breaking
the panel.
