Pro-Form 535 - Completing Assembly; Attaching Handrails and Latch; Final Checks and Floor Protection

6
5. Attach the Storage Latch (14) to the left Upright (11) with
two Latch Screws (35). Be careful not to overtighten
the Latch Screws.
6. Make sure that all parts are tightened before you use the treadmill. Keep the included allen wrench in a
secure place. The allen wrench is used to adjust the walking belt (see page 13). To protect the floor or carpet,
place a mat under the treadmill.
35
14
11
5
3. Insert one of the Handrails (1) into the tube at the upper
end of the right Upright (11). Make sure that the flat part
of the Handrail is on top.
11
1
3
4. Align the hole in the Handrail (1) with the hole in the
Upright (11). Using the allen wrench, tighten a Handrail
Screw (53) into the Upright and the Handrail.
Attach the other Handrail to the left Upright (not shown)
as described above.
1
4
Bottom View
53
11
