M10 Nylon Locknut (97)
M10 x 25mm Screw (121)
M10 x 45mm Bolt (112)
M6 Washer (101)
M8 Washer (100)
M8 Nylon Locknut (96)
M6 x 38mm Screw (102)
1/4” x 14mm Screw (119)
1/4" x 9.5mm Allen
Head Set Screw (120)
M10 x 50mm Screw (108)
M10 x 19mm Screw (118)
M10 x 19mm Hex Head Bolt (132)
M6 Nylon Locknut (124)
M8 x 16mm Screw (98)
25mm Round Outer Cap (94)
25mm Retainer Ring (93)
M6 x 16mm Screw (104)
M4 x 16mm Screw (107)
M8 x 16mm Shoulder Bolt (129)
M8 x 12mm Shoulder
Bolt (131)
M10 Washer (99)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly
. The number in parentheses by each drawing is
the key number of the part, from the PART LIST in the center of this manual.
Important: Some parts may have
been pre-assembled for shipping purposes. If a part is not in the parts bag, check to see if it has been
pre-attached. If a part is missing, call toll-free 1-877-992-5999.
