5
3. Insert the Foot Bar (32) into the end of the Inner
Frame (2). Attach two Cap Legs (14) to the ends
o
f the Foot Bar. M
ake sure that the Cap Leg
with the warning decal is attached in the posi-
t
ion shown.
5. Attach the Headrest (9) to the long ends of the
Headrest Frames (7) with four M6 x 18mm
Screws (36).
Make sure that the Headrest over-
laps the Carriage (6), as shown in step 6.
Tighten the four M6 x 18mm Screws (36) used
in step 4.
4. Rest the exercise bench on its side for this step.
Attach the short ends of the two Headrest Frames
(7) to the bottom of the Carriage (6) with four M6 x
18mm Screws (36).
Do not tighten the Screws.
3
4
5
32
2
14
9
6
7
36
36
36
36
7
7
6
Warning Decal
To Next Page
