6
7. Attach the Seat (10) to the Seat Carriage (6) with
four M6 x 16mm Button Screws (68) and four M8
Flat Washers (80).
6
10
68
80
80
68
7
6. Attach a Handlebar (11) to one side of the Seat
Carriage (6) with two M6 x 35mm Button Bolts (70)
and two M6 Nylon Locknuts (71). Attach the other
Handlebar in the same way.
6
6
11
71
11
70
8. Attach the Backrest (9) to the Seat Carriage (6) with
four M6 x 16mm Button Screws (68).
68
9
6
8
9. Hold the Seat Carriage (6) and lift the Seat
Adjustment Tab (79). Slide the Seat Runners (72)
into the Seat Rail (7).
72
79
6
7
9
