8
3. Attach the other Stabilizer (3) to the Seat Frame
(2) with two M8 x 50mm Carriage Bolts (13), two
M8 Curved Washers (14), and two M8 Acorn
Nuts (15).
4. Attach the Seat (5) to the Seat Post (4)
with three M8 Locknuts (16) and three M8
Washers (17).Note: The Locknuts and Washers
may be preattached to the Seat.
5. Insert the Seat Post (4) into the Seat Frame (2).
Next, insert the Seat Knob (12) into the Seat
Frame (2) and into one of the adjustment holes
in the Seat Post (4); make sure that the Seat
Knob is in one of the adjustment holes in the
Seat Post. Then, tighten the Seat Knob.
3
4
5
14
13
3
4
5
2
14
15
16
16
17
17
2
4
12
15
