9
8. The Console (8) requires two AA batteries (not
included); alkaline batteries are recommended.
Do not use old and new batteries together or
alkaline, standard, and rechargeable batter-
ies together. IMPORTANT: If the Console has
been exposed to cold temperatures, allow
it to warm to room temperature before you
insert batteries. Otherwise, you may dam-
age the console displays or other electronic
components.
Press the tab on the battery cover, and remove
the battery cover. Next, insert two batteries into
the battery compartment; make sure to orient
the batteries as shown by the diagram inside
the battery compartment. Then, reattach the
battery cover.
6
7. Pull the Console Mount (7) open slightly and
slide it onto the Handlebar (6) and onto the
upper end of the Handlebar Frame (1). Then,
tighten an M4 x 25mm Screw (22) into the
Console Mount; do not fully tighten the
Screw yet.
6. Attach the Handlebar (6) to the Handlebar
Frame (1) with two M8 x 35mm Screws (21),
two M8 Split Washers (20), and two M8 Curved
Washers (14).
7
8
Battery
Cover
1
6
20
21
14
14
22
6
8
1
7
To Next Page
