Pro-Form Smart Power 10.0 User Manual

11
8. See the inset drawing. Connect the connector
on the Upper Wire (B) to the connector on the
Lower Wire (82).
Next, tighten the zip tie (D) around the indicated
mark (E) on the Upper Wire (B). Then, cut off the
excess zip tie.
8
B
82
D
D
E
B
82
9
9. Tip: Avoid pinching the wires. Press the Motor
Cover (38) onto the Frame (1), and then attach it
with an M4 x 20mm Screw (87).
87
38
1
Avoid
pinching
the wires

Pro-Form Smart Power 10.0 Specifications

General

Brand	Pro-Form
Model	Smart Power 10.0
Category	Exercise Bike
Language	English
