4. Attach the Seat Frame (5) to the Seat Base (1)
with the indicated two M10 x 100mm Screws (45).
3. Insert two M10 x 100mm Screws (45) up through
t
he Base Plate (34), the Seat Base (1), and the
R
ight and Left Seat Bases (2, 3).
Attach the Right and Left Seat Bases (2, 3) to the
Seat Base (1) with two M10 x 58mm Button Bolts
(
48) and two M10 Nylon Locknuts (74).
3
48
2
3
1
74
34
45
4
5
1
45
5. Attach the Backrest (11) to the Backrest Frame
(8) with four M6 x 15mm Button Screws (40).
8
1
1
40
5
40
To Next Page
