8. Attach the Seat (12) to the Seat Frame (5) with
four M6 x 63mm Button Screws (43) and four M6
Washers (44).
12
8
5
44
43
43
Grease
7
7. Attach the Seat Bumper (27) to the Seat Frame
(5) with an M4 x 16mm Self-tapping Screw (38)
and an M5 Washer (39).
Grease an M10 x 82mm Button Bolt (49). Attach
the Leg Lever (6) to the Seat Frame (5) with the
Bolt and an M10 Nylon Locknut (74).
Do not
overtighten the Locknut; the Leg Lever must
be able to pivot easily.
6. Grease the M10 x 87mm Button Bolt (50). Attach
the Backrest Frame (8) to the Seat Frame (5)
with the Bolt and an M10 Nylon Locknut (74). Do
not overtighten the Locknut; the Backrest
F
rame must be able to pivot easily.
Engage the Backrest Knob (22) into the Backrest
Frame (8) and the Seat Frame (5). Fully tighten
t
he Knob.
6
5
8
50
74
22
5
7
49
74
27
39
38
6
Grease
To Next Page
