T1 Phono SB SPECIFIC
INFORMATIONS
Controls, features and connections
1 ON/OFF SWITCH
2 MOTOR PULLEY
3 SPEED SELECTOR
4 PHONO/LINE OUTPUT, EARTH CONNECTION
5 PHONO/LINE OUTPUT SWITCH
6 POWER SUPPLY SOCKET
__________________________________________________________________________________________
Switching on and off, changing replay speed
Pressing the ON/OFF switch starts the motor of the turntable. Pressing the speed selector selects between 33
r.p.m. and 45 r.p.m. The selected speed is shown respectively by the flashing LED. When the platter has
attained full speed, the LEDs stop flashing.
Connection to the amplifier
The record player has gold plated female RCA phono sockets and possibility to choose between Phono and LINE
output. With LINE OUT on, you can use a line input (such as AUX, CD, Tuner, Tape or Video) on your amplifier.
With PHONO OUT on, you can use your own phono pre-amplifier (sometimes labelled gram, disc or RIAA).
