Pro-Leaf Aqua-Pro - Technical Specifications

Technical Specications
Product Aqua-Pro
Model Aqua-Pro-IE
Protection Level IP20
Operating Temperature 0~50 degrees Celsius
Operating Humidity ≤90%, non-condensing
Operating Voltage DC110V-230V
Operating Current ≤50mA(no sensors, devices connected)
Power Adapter Input DC24V, 2A, Inteace: DC005-2.5
Screen 5 inch LCD monitor, Resolution: 800*480
Network Po RJ45
Communication parameters RS485 host, baud rate 9600, no parity, 8 data bits and 1 stop bit
Ceication ETL, FCC, CE
NC/NO Po D Contact Alarm Output, Load Voltage: ≤30V; Load Current: ≤1A
Sensor Po RJ12, 6P6C, RS485, Output Voltage: 24V, Output Current: 0.5A
Adapter Po RJ12, 6P6C, RS485, Output Voltage: 24V, Output Current: 0.5A
Light Controller Po RJ12, 6P6C, RS485, Output Voltage: 24V, Output Current: 0.5A
Note: Two light controllers cannot be used at the same time.
Number of sensors
connected
The total number does not exceed 6, and the total current does not
exceed 0.5A, which can be connected:
Number of devices
connected
The total number does not exceed 6, and the total current does not
exceed 0.5A(when the power consumption of the device may exceed
0.5A, the device needs to have its own power supply).
AC Remote Station (BTS-AR) x1
CO2 Device Station, PPM Up (BCS-PU1) x1
Control Board (BCB-12) x1
D Contact Station (BDC-4) x2
Sma Socket 120-240V (BSS-4) x6
Light Adapter (LDA-1) x2
4 Channels Light Dimmer (LDA-SPE) x1
4 in 1 Sensor (BLS-4) x1
Water Level Sensor (BLS-WL) x1
Smoke Dector (BLS-SD) x1
Water Detector (BLS-WD) x1
pH/EC/Temp Sensor Board (BSB-I) x1
Moisture Monitoring (BLS-MM) x1
03
