Replace peristaltic pump inner tube
06
Gently unscrew the 4 screws of the pump head to separate the pump head from
the pump body.
Open the pump head, remove the peristaltic pump inner tube to replace the
new peristaltic pump inner tube, cover the upper cover, make sure the peristal-
tic pump inner tube is xed in the bottom cover slot.
Align the pump head with the screw hole of the pump body, tighten the four
screws, and the peristaltic pump inner tube is replaced.
Pump body
Upper cover Lower cap
Screws Peristaltic pump inner tube
Pump head
1.
2.
3.
