3
Continuity Test
Detection Range 0~1MΩ
Test Current Approx. 1.5µA (battery 3V, 0Ω)
Internal Battery Consumption Approx. 30mA (battery 3V, 0Ω)
Reference Condition
Battery 3V(IEC LR03 1.5V x 2)
Temperature
-10~55°C operation
-20~60°C storage
No condensation
Humidity Max 85% RH
Used location Altitude up to 2000m
Safety
Standard category
IEC 61010-1
GS: CAT III 690V
ETL: CAT IV 600V
Pollution degree 2
IP code IP64
FEATURES
• Self-Diagnostic test
• AC and DC voltage tests up to 690V with LED and LCD (model 7339 only)
• Polarity indication
• High voltage indication
• Phase rotation test
• Continuity test
• Auto power ON/OFF
• Pen light for illuminating measurement points
• Probe clip for adjustable spacing between probes
• Probe cover protects user and probe tips
• IP64 (see page 10)
• Compact design (lightweight and portable)
• Use thick wire H07RNF for Europe
• Use thin wire GET6206 for America
