For technical questions call: 1-800-665-8685
8319683 / 8319709
V 1.35
2
SPECIFICATIONS
Voltage Test
Voltage range 12~690V AC/DC
LED (SS~7337 / 7339)
Nominal Voltage
Europe: 12/24/50/120/230/400/690V
America: 12/48/120/208/240/277/480/600V
AC (0~70Hz), DC(±)
Tolerance
(Threshold Voltage)
Light on at more than
: 7±5V (12V LED)
: 18±5V (24 LED)
: 37.5±5V (50V LED)
: 75%±5% of nominal voltage
(120/230/400/690V LED)
Response Time <0.5s at 100% of each nominal voltage
LCD (model 7339 only)
Range/Resolution (Auto-range) 7~690V/1V
Accuracy (23±5°C) ±(3%+3) or 5V
Over range indication All voltage LED light up
Response Time <2s at 90% of each voltage
Peak Current Is <3.5mA (at 690V)
Internal Battery Consumption Approx. 33mA (Battery 3V, measuring 690V AC)
High Voltage Indication
Voltage Range 100~690V AC
Phase Rotation Test
System Three-phase 4-wire system AC 50/60Hz
Phase Range 120±5 degree
