8836363 40-TON HYDRAULIC SHOP PRESS V1.0
18 For technical questions call 1-800-665-8685
PARTS LIST – PRESS
#
DESCRIPTION
QTY
1
Bolt
4
2
Bolt
8
3
Base section
2
4
Support bar
4
5
Post
2
6
Bolt
8
7
Nut
8
8
Lock washer
8
9
Bolt
4
10
Ram
1
11
Lock washer
4
12
Nut
4
13
Bed frame pin
2
14
Lower cross member
1
15
Nut
12
16
Lock Washer
12
17
Washer
12
18
Lock nut
4
19
Pull-rod
2
20
Bolt
4
21
Bed frame
1
22
Heel block
2
23
Coupler nut
1
24
Gauge coupler
1
25
Nylon ring
1
26
Pressure gauge
1
27
Bolt
4
28
Washer
4
29
Pump body
1
30
Upper cross beam
1
31
Hydraulic hose
1
