pro.point 8836363 - Page 19

V1.0 40-TON HYDRAULIC SHOP PRESS 8836363
Visit www.princessauto.com for more information 19
PARTS LIST – RAM
#
DESCRIPTION
QTY
R1
Dust cover
1
R2
O-Ring
1
R3
Ram coupler
1
R4
Coupler nut
1
R5
Pin
2
R6
Ram
1
R7
Seal ring
1
R8
Washer
1
R9
Piston head
1
R10
Spring
2
R11
Piston rod
1
R12
Screw
1
R13
Ram cover
1
R14
Spring hook saddle
1
R15
Serrated saddle
1
R16
Screw
1
