8913204 Gas Engine V1.0
24 For technical questions call 1-800-665-8685
PARTS LIST
# DESCRIPTION QTY
1 Crankcase 1
2 Ball Bearing 2
3 Oil Seal 2
5 Governor Arm Shaft 1
6 Rocker Oil Seal 1
7 Governor Arm Shaft Washer 1
8 Lock Pin 1
9 Drain Plug Bolt 2
10 Drain Plug Washer 2
11 Oil Level Switch Assembly 1
12
Bolt M6
x
16
3
13 Crankcase Cover Pin 2
14
Rocker Arm Fastening Bolt
Assembly
2
15 Piston 1
16 Piston Ring Set 1
17 Connecting Rod Assembly 1
18 Piston Pin 1
19 Piston Clip 2
20
Crankcase Cover
Assembly
1
21 Oil Plug 1
22 Cylinder Head 1
23 Intake Valve 1
24 Exhaust Valve 1
25 Valve Return 2
26 Valve Oil Seal 2
27 Valve Lock Clip 4
28 Valve Spring Seat 2
29 Valve Spring 2
30 Push Rod Guide Plate 1
31 Rocker Assembly 2
32 Rotator 2
33 Stud Bolt 2
34 Engine Oil Sensor 1
35 Stud Bolt 2
36 Carburetor Components 1
37 Fuel Line 1
38 Fuel Line Clip 2
39 Governor Arm 1
40 Governor Arm Bolt 1
41 Nut 2
43 Valve Lifter 2
44 Crankcase Gasket 1
45 Dowel Pin 2
46 Spark Plug 1
47 Lock Bolt 1
48
Bolt M10
x
80
4
49 Push Rod 2
50 Shroud 1
51
Bolt M6 x 12
9
52 Cylinder Head Cover 1
53 Cylinder Head Cover Gasket
1
54 Flywheel Assembly 1
55 Recoil Starter Fan 1
56 Starter Pulley 1
57 Nut M14 1
58
Bolt M6
x
25
2
59 Intake Port Gasket 1
60 Spacer 1
