V1.0 Gas Engine 8913204
Visit www.princessauto.com for more information 25
62 Air Cleaner Gasket 1
63 Governor Rod 1
64 Throttle Return Spring 1
65 Recoil Starter Assembly 1
66 One Way Valve 1
67 Throttle Assembly 1
68
Bolt M8 x 35
9
69 Air Cleaner Assembly 1
70 Breather Tube 1
71 Clip 1
72 Governor Spring 1
73
Breather Pipe Sleeve
1
74 Exhaust Port Gasket 1
75 Muffler 1
76 Muffler Pipe Gasket 1
77 Muffler Pipe 1
78 Nut M8 5
79
Spring Washer
Φ
8
2
80 Dipstick 1
81 Fuel Tank Assembly 1
82 Cylinder Head Gasket 1
83 Metal Clip 1
84 Bolt 2
85
Bolt M8 x 25
1
86 Fuel Tank Cap 1
87 Check Valve Assembly 1
88
Camshaft Assembly
1
89 Connecting Pipe 1
90 Fuel Pipe Clamp Ring 1
91 Fuel Pipe Clamp Ring 1
92 Ignition Components 1
93 Balancing Shaft 1
94 Ball Bearing 1
95 Clip 1
96 Engine Switch Subassembly 1
