Pro's Kit MT-1707 - Technical Parameters; Frequency; Duty; DC Current

22
4.2.8 Frequency
Measuring range
Resolution
Accuracy
9.999Hz
0.001Hz
± (1% Reading +3 digits)
99.99Hz
0.01Hz
999.9Hz
0.1Hz
9.999KHz
0.001 KHz
99.99KHz
0.01 KHz
999.9KHz
0.1 KHz
9.999MHz
0.001MHz
Input voltage range: 200mV-10V ac valid value
Overload protection: 600V DC/AC
4.2.9 Duty
Measuring range
Resolution
Accuracy
0.1%～99.9%
0.1%
(Reference）
Input voltage range: 200mV-10V ac valid value
Overload protection: 600V DC/AC
4.2.10 DC current
Measuring range
Resolution
Accuracy
600uA
0.1uA
±(0.8% Reading + 3 digits)
60mA
0.01mA
600mA
0.1mA
10.00A
10mA
±(1.5% Reading + 10 digits)
Overload protection:
Protective tube for uA mA measuring range (F500mA/250V) ; Protective
tube for 10A measuring range (F10A/250V) .
Maximal input current: mA position: 600mA DC/AC (valid value);
10A position: 10A DC/AC (valid value) When the
measured current is over 5A, the duration of continuous measurement shall
